CMC · Textile printing & sizing
Textile Printing & Dyeing CMC
Warp sizing and printing-paste thickener — sharp prints, easy wash-off.
[01]Overview
Sentai textile CMC replaces starch in warp sizing and serves as an economical thickener for reactive-dye printing pastes, partly replacing sodium alginate. High-DS grades give clean wash-off and crisp outlines with good colour yield.
- Typical dosage
- Sizing 0.3 – 1.5 %; printing paste 0.5 – 2.0 %
- HS code
- 3912.31
- CAS No.
- 9004-32-4
What it does
- 01Warp sizing film — abrasion resistance and fewer breaks
- 02Printing-paste thickener for reactive dyes
- 03Easy desizing and wash-off
- 04Finishing and stiffening agent
[02]Grades & specifications
5 grades
Values are specification limits. Typical values and test methods are on the full TDS (Customer Portal or on request).
| Grade | Viscosity · mPa·s | DS | Purity % | pH | Moisture % | Spec sheet |
|---|---|---|---|---|---|---|
| IH-8 | 400–700 @1% | ≥ 0.8 | ≥ 80 | 6.5–8.5 | ≤ 10 | Spec sheet → |
| IH-9 | 800–1200 @1% | ≥ 0.9 | ≥ 90 | 6.5–8.5 | ≤ 10 | Spec sheet → |
| IH-10Highest DS · printing | 800–1200 @1% | ≥ 1.2 | ≥ 90 | 6.5–8.5 | ≤ 10 | Spec sheet → |
| IM-9 | 300–500 @1% | ≥ 0.9 | ≥ 90 | 6.5–8.5 | ≤ 10 | Spec sheet → |
| IM-10 | 100–300 @1% | ≥ 1 | ≥ 90 | 6.5–8.5 | ≤ 10 | Spec sheet → |
Viscosity windows
Brookfield viscosity, mPa·s, 25 °C — log scale
Grade map
Each bubble is a grade: degree of substitution on the horizontal axis, minimum purity on the vertical, bubble size by viscosity.
[03]Applications
Textile printing & sizing
- Cotton and blended warp sizing
- Reactive and disperse printing
- Dyeing auxiliaries
- Non-woven binders
[05]Packaging & supply
Packed for export.
- Packaging
- 25 kg kraft-composite or PP woven bag with food-grade PE liner · 500 kg / 1 t jumbo bags
- Palletising
- 40 bags = 1 t per pallet, fumigation-free plywood, stretch-wrapped
- Container load
- 20′ GP ≈ 17–20 t · 40′ HQ ≈ 25–28 t
- MOQ
- 1 t for industrial grades · battery grade negotiable
- Lead time
- 7–15 days (stock grades) · 20–30 days (custom)
- Samples
- Free 100–300 g samples, courier collect
- Payment
- T/T 30% deposit, 70% against B/L copy · L/C · D/P
- Incoterms
- FOB · CFR · CIF · EXW
- Documents
- COA · TDS · MSDS/SDS · CO · Form A · Form E
- Inspection
- Customer-appointed SGS / BV inspection accepted
- Port of loading
- Guangzhou — other South China ports on request
Qualify it in your process.
Free 100–300 g samples with COA, shipped within days. Tell us your formulation and target viscosity — our applications lab will suggest the closest grade.
